Explorer Post 1010
Lockheed Martin Exploring Program
Launch March 31, 2007


This was our big day - qualification flights.  We again traveled to the Great Meadows launch site in Virginia.  It was a warm day with winds mostly under 10mph.  We used the provided launch rods.  We set the angles between 5 and 10 degrees.  We had great scores.  All three teams may be heading to the National Fly Off.

Objectives:

  • Get good TARC Qualification scores.
    • Team 2 - Rear Daddy V4 with F24-4 (two tests and two qualifications)
    • Team 1 - Executioner V2 with E18-4 (one test and two qualifications)
    • Team 3 - Fat Boy Design V2 with E9-6 (one test and two qualifications)
  • Have two members work the reloads - one working, one watching.

Lessons:

  • If you have a problem during a competition, always ask the judges for help. We had a problem with the Team 1 first qualification launch so they let us do it again.
  • Bring towels when there are ponds around the launch area.
  • The launch rod angles proved critical.  We watched the wind and flights that preceded ours -- making adjustments to correct for cocking into the wind.
  • The F24 engines worked good on the Rear Daddy when we added 60 grams to the nose.

Launches

Flight Order Load Results Comment
Rear Daddy V4
Flight 1
(no video)
1 E9-4,  330g
Wood Egg, Altimeter Weight,
2-12" Chutes
(no data) This was the initial test flight of V4
Rear Daddy V4
Flight 2
(no video)
4 F24-4,  390g
Egg, Altimeter A,
2-12" Chutes
39sec,
828ft
Altimeter Data
Score: 28 - Straight flight, chutes deployed nice, extra weight in nose cone, but landed in the pond
Rear Daddy V4
Flight 3 (Video)
Qualification
8 F24-4,  390g
Egg, Altimeter (personal),
2-12" Chutes
45sec,
853ft,
Altimeter Data
Score: 3 - Chutes deployed nice, extra weight in nose cone, very nice flight

Executioner V2
Flight 1 (Video)
2 E18-4,  336g
Egg, Altimeter A,
18" X-Chute
45sec,
858ft,
Altimeter Data
Score: 8 - Test flight, some wind cocking, straight flight, nice flight
Executioner V2
Flight 2 (Video)
5 E18-4,  335g
Egg, Altimeter A,
18" X-Chute
33sec,
633ft,
Altimeter Data
Score: 229 - Parachute ejected at engine cutoff, no glide to apogee, judge gave us a CATO
Executioner V2
Flight 3 (Video)
Qualification
7 E18-4,  335g
Egg, Altimeter A,
18" X-Chute
44sec,
842ft,
Altimeter Data
Score: 9 - Nice flight

Fat Boy Design V2
Flight 1 (Video)
3 E9-6,  262g
Egg, Altimeter B,
14" Chute
44sec,
840ft,
Altimeter Data
Score: 11 - Test flight, some wind cocking, nice flight, but egg cracked
Fat Boy Design V2
Flight 2 (Video)
Qualification
6 E9-6,  264g
Egg, Altimeter B,
14" Chute
58sec,
880ft,
(no data)
Score: 43 - Very straight flight
Fat Boy Design V2
Flight 3 (Video)
Qualification
9 E9-6,  266g
Egg, Altimeter B,
14" Chute
47sec,
835ft,
Altimeter Data
Score: 17 - Nice flight

Pictures

Team 1 loading
Team 3 loading
